| Brand Name : | Super Diamond |
| Price : | 30-500 |
| Payment Terms : | L/C,T/T |
| Delivery Time : | 5-8 DAYS |
| Model Number : | DHD,QL,Mission,SD |
We are a leading manufacturer for various of high air pressure rock
drilling tools, incl. DTH hammers and bits, RC hammers and bits,
top hammer button bits, ODEX etc. Our factory locates in LiuYang
city, HuNan province, China, where occupies an area of 26,600
square meters, and production facility occupies 22,000 square
meters.
Premium quality, professional serivce and competitive price, help
us get very good reputation from our worldwide customers, not only
from the domestic, also from Brazil, Peru, South Africa, Australia,
Turkey, Russia, Ukraine, Korea etc..
Product Description:
| Hammers | Bit Shank | Connection Thread | Suitable bit | Working pressure | Air consumption | |
| 1-3" Middle-low pressure DTH hammers | BR1 BR2 BR3 | RD40 box RD50 box API 2 3/8" Reg | ¢64-¢76mm ¢70-¢90mm ¢90-¢110mm | 0.7-1.75Mpa 0.7-1.75Mpa 0.7-1.75Mpa | 0.7Mpa | 4.5m3/min |
| 1.0Mpa | 4m3/min | |||||
| 1.4Mpa | 5m3/min | |||||
| 3" hammers | DHD3.5 COP32/COP34 M30 | API 2 3/8"Reg | ¢90-¢110mm | 1.0-1.5Mpa | 1.0Mpa | 4.5m3/min |
| 1.5Mpa | 9m3/min | |||||
| 4" hammers | DHD340 COP44 QL40 SD4 M40 | API 2 3/8"Reg | ¢105-¢130mm | 1.0-2.5Mpa | 1.0Mpa | 6m3/min |
| 1.8Mpa | 10m3/min | |||||
| 2.4Mpa | 15m3/min | |||||
| 5" hammers | DHD350 COP54 QL50 SD5 M50 | API 2 3/8"Reg/API 3 1/2"Reg | ¢130-¢156mm | 1.0-2.5Mpa | 1.0Mpa | 9m3/min |
| 1.8Mpa | 15m3/min | |||||
| 2.4Mpa | 23m3/min | |||||
| 6" hammers | DHD360 COP64 QL60 SD6 M60 | API 3 1/2"Reg | ¢152-¢203mm | 1.0-2.5Mpa | 1.0Mpa | 10m3/min |
| 1.8Mpa | 20m3/min | |||||
| 2.4Mpa | 28.5m3/min | |||||
| 8" hammers | DHD380 COP84 QL80 SD8 | API 4 1/2"Reg | ¢200-¢279mm | 1.0-2.5Mpa | 1.0Mpa | 15m3/min |
| 1.8Mpa | 26m3/min | |||||
| 2.4Mpa | 34m3/min | |||||
| 10" hammers | SD10 NUMA100 | API 6 5/8"Reg | ¢254-¢330mm | 1.0-2.5Mpa | 1.0Mpa | 22m3/min |
| 1.8Mpa | 40m3/min | |||||
| 2.4Mpa | 55m3/min | |||||
| 12" hammers | DHD1120 SD12 NUMA120 NUMA125 | API 6 5/8"Reg | ¢305-¢381mm | 1.0-2.5Mpa | 1.0Mpa | 30m3/min |
| 1.8Mpa | 56m3/min | |||||
| 2.4Mpa | 78m3/min | |||||
Why choose us:
1. High quality raw material, with premium hardened procedures for
long life.
2. Full production chain to secure stable and prompt production
leadtime.
3. Experienced Senior Technicians.
4. Long year experienced workers and engineers.
5. Quick and efficient service.
6. Care customers' concerned.
7. Customized acceptable.
FAQ
The information you may like to know before order:
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. Handling time for an order
Based on order quantity, normally it takes 25 days for production.
Only 2 or 3 days if we have stock on your request size.
3. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before
shipping out.
5. Can you customize the product?
We can customize products according to your required diameter, face shape, button size and color. We can produce by your samples or technical drawings. 5 types of face shapes Selection:
1. The Concave Face
2. The Flat Face
3. Double the Gauge Face
4. The Convex Face
5. The Drop Center
and 5 types of Carbide Button Shape Selection:
1.Ballistic Button
2.Sharp Button
3.Parabolic Button
4.Flat Button
5.Domrd/Round button
6. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
c. Free replacement will provide once the failure confirmed caused by our product quality
|
|
